Stone Processing Machinery

Home > Product > Stone Carving Machine

Atc Linear Automatic Tools Changer CNC Router for Wood Furniture Kitchen Cabinet Door 1325

Jinan Allwin CNC Machinery Co., Ltd.
  • Application Material：Wood
  • Automation：Automatic

Base Info

  • Model NO.：1325
  • Control：CNC
  • Motor Power：High Power
  • Engraving Head Speed Adjustability：Wide Adjustable Range
  • Certification：CE, ISO, API
  • Current：AC
  • Application：Glass, Ceramics, Decoration, Advertising, Art & Craft, Stela & Gravestone, Stone Industry
  • Customized：Customized
  • Service：Offering Oversea Service
  • Voltage：220,380V
  • Table：T-Slot Aluminum +PVC or Vacuum
  • Spindle Power：3kw(Without Spindle)
  • Driver：Leadshine M860
  • Motor：Stepper Motor 450b
  • X,Y,Z Traveling：X, Y, Z Traveling
  • Inverter：Fuling or Delta
  • Control System：Weihong or DSP or Syntec
  • Tool Change：Automatic
  • Spindle：9.0kw Air Cooled
  • Transport Package：Woodencase
  • Specification：1300x2500x300
  • Trademark：ALLWIN
  • Origin：Jinan, Shandong
  • HS Code：8465990000
  • Production Capacity：500
  • Package size per unit product：320.00cm * 210.00cm * 170.00cm
  • Gross weight per unit product：1100.000kg

Description

Parameter1ModelALLWIN1325C2ALLWIN1530C2ALLWIN2030C2ALLWIN2040C22X,Y,Z Working Area1300x2500x250mm1500x3000x250mm2000x3000x250mm2000x4000x250mm3Table Size2150x3420mm2350x3920mm2850x3920mm2850x4920mm4X,Y,Z Traveling Positioning Accuracy0.01/300mm5X,Y,Z Repositioning Accuracy0.03mm/300mm6Table SurfaceT-slot and vacuum working table7FrameHeavy Steel Tube Structure8X,Y StructureRack and pinion Drive,Hiwin Rail Linear Bearings9Z StructureHiwin Rail Linear Bearings and Ball Screw10Max. Power Consumption(Without Spindle)5.8KW11Max. Rapid travel Rate50000mm/min12Max. Working Speed30000mm/min13Spindle Poweer9.0KW air cooling spindle ,ATC spindle14Spindle Speed0-18000RPM15Drive MotorsServo motor16Working VoltageAC380V/50/60HZ,3PH(Option:220V)17Command LanguageG Code18Operation SystemTaiwan Syntec control system19Computer InterfaceUSB/ Ethernet20Flash Memory512M21ColletER3222X,Y Resolution<0.03mm23SOftware ConpatibilityType3 / Artcam software24Running Environment Temperature0-45 Centigrade25Relative Humidity30%-75%26Packing Size3670x2270x2080mm4170x2270x2080mm4170x2270x2080mm5170x2270x2080mm27N.W.1250KG1500KG1750KG1950KG28G.W.1450KG1750KG2050KG2250KG


Advantages:

1. Free samples(I can help you process samples for free.)

2.Advertising/artwork/woodworking

3.CE, SGS,ISO

4.Customized:Yes

5.High sensitivity

6.High efficiency

7. Warranty: 1 year
8.Door-to-door technical service and 24 hours technology online support

Application Industry and Materials:

Advertising industury:Cnc router can engrave all kinds of signage,logo  products,trademarks,nameplates,badges,decorative gift,embossed
medals,certificates,souvenirs,photo frames,furniture decoration,PVC plates, PCB boards

(drilling and engraving),Double color boards,acrylic etc.

Woodworking Industry:Cnc router can be used for solid wood furniture,mahogany furniture,

MDF paint doors,solid wood doors,composite doors,cupboard doors and windows,beside

cabinets,folding screen etc.

Artwork industry: in the wood, bamboo, organic board, double color plate, crystal and other materials on a variety of exquisite patterns and text engraving.

.Packing & shipment :

Save space as much as possible for container loading.

  • Inside:Water-proof Plastic Film Package With Foam Protection
  • Outside:Solid Seaworthy Wood Box Package
  • Below: Steel Tuble
