Electric Wheel Head Moving Surface Grinder

Qingdao G & G Machinery Co., Ltd.
  • Type：Metal Grind Machine
  • Control：Artificial
  • Automation：Semi-automatic
  • Precision：Precision
  • Application：Metal Grding Machine
  • Type for Grinding Machine：Disc Grinding Machine

Base Info

  • Model NO.：M7130
  • Grinding Machine Type：Vibration Polishing Machine
  • Grinding Method：Semi-Dry Grind
  • Condition：New
  • Table Size(Wxl)：300X1000 mm
  • Max. Machining Dimension(Wxl)：300X1000 mm
  • Max. Distance Between Spindle：575mm
  • Motor Power：5.5lw
  • Max. Loading Capacity of Worktable with：470kg
  • Transport Package：Plywood
  • Specification：CE
  • Trademark：customer brandv
  • Origin：China China
  • HS Code：8466200
  • Production Capacity：50sets, Per Month

Description

M71 wheel head moving surface grinder  Item/ModelUnitM7130table size(WxL)mm300x1000max. machining dimension(WxL)mm300x1000max. distance between spindle center line and worktable surfacemm575longitudinal moving speed of worktablem/min5-25T-slot number x Wmm3x18wheel head cross movingcontinuous feed speedm/min0.5-4.5intermittent feed speedmm/t3-30hand wheel feedmm/gra wheel head vertical movingrapid speedmm/min feed of handwheelmm/gra0.005wheel head motorpowerkw5.5rotation speedrpm1440total powerkw8.63max. loading capacity of worktable with chuckkg470chuck size (W x L)mm300x680x1wheel size (ODxWxID)mm350x40x127machine dimension(LxWxH)cm286x154x203package dimensions(LxWxH)cm284x171x213machine weightt3.49
