Stone Processing Machinery

50-850tph Rock Jaw Stone Crusher (PEW400X600, PEW760, PEW860)

Shanghai Zenith Mineral Co., Ltd.
  • Type:Jaw Crusher
  • Application:Construction, Mineral Industry, Stone Industry
  • Drive:Electric
  • Crushing Style:Grinding & Impact
  • Compressive Strength (For Crushing):>300MPA
  • Crushing Degree:Coarse Crusher

Base Info

  • Model NO.:PEW250x1200, PEW400x600, PEW760, PEW860
  • Finished Surface:Hole Process
  • Certification:CE, ISO
  • Condition:New
  • Color:Iron Grey
  • Spare Parts Supply:for Whole Year
  • Test&Installation:Engineer Assigned
  • After-Sale Service:for Whole Using Life
  • Export Markets:Global
  • Transport Package:Container, Nude Packs, in Bulk
  • Specification:ISO9001: 2000
  • Trademark:Zenith
  • Origin:China
  • HS Code:8474209000
  • Production Capacity:1000 Set,Year

Description

Basic Info.

Model NO. PEW250x1200, PEW400x600, PEW760, PEW860 Finished Surface Hole Process Certification CE, ISO Condition New Color Iron Grey Spare Parts Supply for Whole Year Test&Installation Engineer Assigned After-Sale Service for Whole Using Life Export Markets Global Transport Package Container, Nude Packs, in Bulk Specification ISO9001: 2000 Trademark Zenith Origin China HS Code 8474209000 Production Capacity 1000 Set/Year

Product Description


Rock Jaw Stone Crusher introduction:


PEW series Jaw Stone Crusher is one of the largest-selling and the highest production efficiency stone crusher in mining equipment.Jaw Crusher used in various rocks shattered the first operation, to various ores of the compressive strength of not more than 320MPa one-time processing to medium-grained, often with cone crusher, impact crusher, sand making machines together constitute the entire sand production line.
50-850tph Rock Jaw Stone Crusher (PEW400X600, PEW760, PEW860)
 50-850tph Rock Jaw Stone Crusher (PEW400X600, PEW760, PEW860)
50-850tph Rock Jaw Stone Crusher (PEW400X600, PEW760, PEW860)

Rock Jaw Stone Crusher operating principle:

Jaw stone crusher uses motor as its power. Through the motor's wheels, the eccentric shaft is driven by the triangle belt and slot wheel to make the movable jaw plate move by a regulated track. Therefore, the materials in the crushing cavity composed of fixed jaw plate, movable jaw plate and side-lee board can be crushed and discharged through the discharging opening.
50-850tph Rock Jaw Stone Crusher (PEW400X600, PEW760, PEW860)

 Main advantages of Rock Jaw Stone Crusher

1. Crushing cavity is deep without dead zone. It is easier to feed materials and yield higher output.

2. It is featured with high crushing ratio and sound deadening.

3. The gasket type adjusting device of the discharge gate is characterized by reliable performance, convenient use, large adjusting range, and improves the equipment flexibility.

4. It is highly energy saving. A single machine saves 15%~30% of energy consumed and the system can save over half the energy consumed.

Application of Rock Jaw Stone Crusher

1. Jaw Stone Crusher is widely applied to crush high hardness, mid hardness and soft rocks and ores such as ore, quartz, granite, limestone, slags, construction materials, marble, etc

2. The maximum compression strength of materials to be crushed is 320MPA.

3. PE series is used for primary crushing, and PEW series is used for secondary crushing and fine crushing.
50-850tph Rock Jaw Stone Crusher (PEW400X600, PEW760, PEW860)

Rock Jaw Stone Crusher technical data:

ModelFeed Opening (mm)Max Feeding (mm)Discharge Opening (mm)REV (r/min)Power (kw)Motor ModelMachine Size (mm)
PEW250×1000250×100022020-403306-37Y250M-6/371400×1850×1310
PEW250×1200250×120022020-403306-37Y250M-6/371400×2050×1310
PEW400×600400×60035035-852506-37Y250M-6/371920×1460×1840
PEW760760×110062075-2002706-110Y315L1-6/1102600×2500×2200
PEW860860×1100720100-2252406-132Y315L2-6/1323300×2320×3120
PEW11001100×1200930150-2752108-185Y355L1-8/1854140×2660×3560
