High Productivity Granite Cutter Saw Marble Cutting Machine for Sale
Shandong Datang Machinery Technology Co., Ltd.- Warranty：1 Year
- Type：CNC Cutting Machine
Base Info
- Model NO.：DTQ
- Usage：Concrete Curb, Granite, Marble
- Application：Machinery & Hardware, Construction, Stone Industry
- Source Voltage：380V
- Automation：Automatic
- Cutting Ability：High Speed
- Control：CNC
- Certification：ISO, CE
- Max. Cutting Size：3200*2000*275mm
- Blade Size：400-800mm
- Work Table Size：3200*2000mm
- Work Table Tilting：0-85 Degrees
- Work Table Rotating：0-90,0-360 Degrees
- Main Motor Power：18.5kw
- Water Consumption：3.5m3,H
- Dimension：6000*4800*3300mm
- Weight：10650kg
- Transport Package：Nude
- Specification：6000*4800*2600mm
- Trademark：Datang
- Origin：China
- HS Code：8464109000
- Production Capacity：600sets,Year
Description
ModelDTQ-450DTQ-600DTQ-700DTQ-800Max. Cutting Size3200*2000*100mm3200*2000*175mm3200*2000*225mm3200*2000*275mmBlade Size400-450mm400-600mm400-700mm400-800mmWork Table Size3200*2000mm3200*2000mm3200*2000mm3200*2000mmWork Table Tilting0-85 degrees0-85 degrees0-85 degrees0-85 degreesWork Table Rotating0-90/0-360 degrees0-90/0-360 degrees0-90/0-360 degrees0-90/0-360 degreesMain Motor Power15kW18.5kW18.5kW18.5kWWater Consumption3.5m3/h3.5m3/h3.5m3/h3.5m3/hDimension6000*4800*2600mm6000*4800*2800mm6000*4800*3150mm6000*4800*3300mmWeight8700kg9200kg10500kg11000kg
