• Model NO.：PEM-3015
• Application：Art & Craft, Stone Industry, Stone Machinery
• Name：Stone Cutting Machine (Diamond Wire Saw Machine)
• Max Processing Size：1300*2500mm
• Main Motor：5.5kw
• Number of Spindles：1PC
• Gross Weight：2000kg
• Water Consumption：1m3,H
• Control Type：CNC
• Certificates：CE, SGS, ISO9001
• Transport Package：Load in a 20 Feet Container
• Specification：4200*2410*2200mm
• Trademark：Xianda
• Origin：Jinjiang, Fujian, China
• HS Code：84641090
• Production Capacity：1000 Sets,Year

Basic Info.

Model NO. PEM-3015 Application Art & Craft, Stone Industry, Stone Machinery Name Stone Cutting Machine (Diamond Wire Saw Machine) Max Processing Size 1300*2500mm Main Motor 5.5kw Number of Spindles 1PC Gross Weight 2000kg Water Consumption 1m3/H Control Type CNC Certificates CE, SGS, ISO9001 Transport Package Load in a 20 Feet Container Specification 4200*2410*2200mm Trademark Xianda Origin Jinjiang, Fujian, China HS Code 84641090 Production Capacity 1000 Sets/Year

Product Description



Application

PEM-2515


This machine adopts numerical control system, three -axis linage, doulbe row four-row slider, constant power spindle motor, two -way toll colling system, with stable running , high efficiency advantages,suitable for processing marble, granite, aluminum plate and other materials.





Technical Parameter

Parameter	Unit	PEM-2515-2D	PEM-2515-3D	PEM-3015-3D	PEM-3015-4D
Dimension of worktable	mm	2500*1500	2500*1500	3000*1500	3000*1500
Feed height	mm	≤350(≤650)	≤350(≤650)	≤380(≤650)	≤380
Air Speed	m/min	15/12	13/10	13/10	10
Number of spindles	pcs	2	3	3	4
Spindle Power	kw	5.5	5.5	5.5	5.5
Outline dimension(L*W*H)	mm	3700*2410*2200  3700*2410*3500	3700*2410*2200 3700*2410*3500	4200*2410*2200  4200*2410*3500	4200*2410*2200
Water consumption	M3/h	2	3	3	4

Factory Overviews

Fujian Xianda Machinery Co.Ltd was established in 1985 and have been dedicated to the development and producing of a serious of column making machine,wire saw stone cutting machine,block trimming machine, bridge saw cutting machine, profiling stone cutting machine etc.
With the rapid development of company ,we have passed the ISO9001 verifing, CE, and won many honory tiles include International Gold Plant Quality Award etc. We keep " Advanced Tecnology and High Quality" as our aim. We have developed a range of 'Xianda' Brand special stone shape processing machines.




Exhibition


Our after-sale service Team


We are a vigorous and creative team with great passion, we are always trying to provide better service for you, if you meet any problems about stone cutting machine, please contact us at any time suits you.

Other stone cutting machines we produce: Diamond wire saw machine, bridge cutting machine, bridge saw and a series of stone machine for special shape processing.



FAQ

1. Manufacturer Profiles

We are the Top 10 stone cutting machine manufacturer with ISO & CE certificate since 1985.
We own 70% China market share at special shape stone cutting machine series.

We are a company which is specially for producing stone machines for exporting.

2. Quality Control

We have our own experienced QC.

Our machine will be strictly inspected.

We will provide a Testing Video for each machines before shipping out if required by customer.

3. Delivery time

Based on order quantity, normally three weeks against payment.

4. Warranty

All the machines have one year warranty.

5. After Services



Our marketing team will response for your question within 24 hours.
Technical support will be available in any time.
Free replacement will provide once the failure confirmed caused by our product quality.

6. Contact





Add: Anqi Road, Wuli Industrial Park, Jinjiang City, Fujian, China.
