• Model NO.：PF series
• Finished Surface：Hole Process
• Certification：CE, ISO
• Condition：New
• Color：Iron Grey
• Spare Parts Supply：for Whole Year
• Test&Installation：Engineer Assigned
• After-Sale Service：for Whole Using Year
• Export Markets：Global
• Transport Package：Container, Nude Packs, in Bulk
• Specification：ISO9001: 2000
• Trademark：Zenith
• Origin：Shanghai Zenith, China
• HS Code：8474209000
• Production Capacity：40-850tph

Basic Info.

Model NO. PF series Finished Surface Hole Process Certification CE, ISO Condition New Color Iron Grey Spare Parts Supply for Whole Year Test&Installation Engineer Assigned After-Sale Service for Whole Using Year Export Markets Global Transport Package Container, Nude Packs, in Bulk Specification ISO9001: 2000 Trademark Zenith Origin Shanghai Zenith, China HS Code 8474209000 Production Capacity 40-850tph

Product Description

Introduction of Impact Crusher for Sale:

Zenith impact crushers is optimized and widely applied in the first and secondary crushing. It can crush material like granite, basalt, bluestone, etc the longest side of which is less than 500mm, and anti-pressure strength is not more than 320Mpa, and the final product is ideal device for aggregation used in highway and railway surface as well as water and electricity industry.

Impact crusher features:

1) Locking sleeve assembly Connection
2) Blow bar with high chrome
3) Hydraulic or hand opening
4) Special impact plate
5) Cubical shape of final product
6) Easy maintenance
7) Reliable performance

Working Principle of Impact Crusher:

When the impact crusher works, the motor drives the rotor rotate of the impact crusher with high speed, on the rotor where installed the hammers. When the materials get into the area which the hammers affect, under the impact function of the hammer at a high speed, the materials are thrown to the impact device above the rotor continuously. And then the materials are rebounded from the impact liner to the area where the hammers effects for being re-crushed. The materials from large to small all to be crushed at the impact chamber repeatedly. The process won't stop till the material are crushed to the required size and then discharged from outlet of the impact crusher.

Impact crusher technical data:


Model	Rotor Φ×L (mm)	Feed Opening (mm)	Max Feeding (mm)	Capacity (t/h)	Power (kw)	Motor Model	Machine Size (mm)
PF1010	Φ1000×1050	400×1080	350	50-80	4-75	Y280S-4/75	2455×2086×2800
PF1210	Φ1250×1050	400×1080	350	60-120	6-110	Y315L1-6/110	2590×2050×2810
PF1214	Φ1250×1400	400×1430	350	80-160	6-132	Y315L2-6/132	2590×2400×2810
PF1315	Φ1300×1500	860×1520	350	120-260	6-200	Y355M3-6/200	2930×2760×3050
