• Model NO.：PEW250x1200, PEW400x600, PEW760, PEW860
• Finished Surface：Hole Process
• Certification：CE, ISO, GOST
• Condition：New
• Color：Iron Grey
• Spare Parts Supply：for Whole Year
• Test&Installation：Engineer Assigned
• After-Sale Service：for Whole Using Life
• Export Markets：Global
• Transport Package：Container, Nude Packs, in Bulk
• Specification：ISO9001: 2000
• Trademark：Zenith
• Origin：China
• HS Code：8474209000
• Production Capacity：1000 Set,Year

Basic Info.

Model NO. PEW250x1200, PEW400x600, PEW760, PEW860 Finished Surface Hole Process Certification CE, ISO, GOST Condition New Color Iron Grey Spare Parts Supply for Whole Year Test&Installation Engineer Assigned After-Sale Service for Whole Using Life Export Markets Global Transport Package Container, Nude Packs, in Bulk Specification ISO9001: 2000 Trademark Zenith Origin China HS Code 8474209000 Production Capacity 1000 Set/Year

Product Description

PEW Series primary jaw crusher with 50-300tph

primary jaw crusher introduction:

primary jaw crusher is very famous in the world, and in the mining processing, jaw crusher is a kind of common crushing machine. It can crush the hard rock which other equipment can not crush. SBM's PE jaw crusher is a high-efficiency and popular machine which widely used in mining, metallurgy, chemical industry, building materials, electricity, water, transportation and other fields. And it is well accepted by quarry operators and mining companies. It is based on our experts' years experiencem, and it has attracted more and more customers. We believe you will love our products after using them.



primary jaw crusher Features:

1. Durable moving jaw assembly.

2. Integral cast steel bearing housings.

3. Fast and safe setting adjustment.

4. Reasonable cavity design.

5. Larger-size and larger-carrying-capacity bearings.

6. Compact & robust structure.

primary jaw crusher Application:

primary jaw crusher is widely used in mining, metallurgy, construction, hydropower and chemical industries etc. To materials, it can be used to crush many kinds of stones, such as the basalt quartz, granite, limestone and sand gravel, etc. Also include the ore materials such as gold ore, manganese ore, iron ore, bauxite, copper ore and coal, etc. At the same time, primary jaw crusher are also applicable for recycling construction waste, slags.


primary jaw crusher Working Principle:

When primary jaw crusher works, through the motor's wheels, the triangle belt and slot wheel drive the eccentric shaft, it makes the movable jaw plate move by a regulated track. Therefore, the materials in the crushing cavity which composed of fixed jaw plate, movable jaw plate and side-lee board can be crushed and the final products will be discharged from the discharging port.


primary jaw crusher technical data:


Model	Feed Inlet Size (mm)	Max Feed Size (mm)	Outlet Range (mm)	Capacity (t/h)	Motor Power (KW)	Weight (ton)	Overall Dimension(mm)
PEW760	760x1100	620	75-200	150-350	110-132	24	2600× 2500× 2200
PEW860	860x1100	720	100-225	200-500	132-160	32	3300× 2320× 3120
PEW1100	1100x1200	930	150-275	300-650	185-200	59.2	4140× 2660× 3560
PEW400x600	400x600	350	35-85	15-70	37	6.8	1920× 1460× 1840
PEW250x1200	250x1200	220	20-40	20-50	37	6	1400× 2050× 1310
PEW250x1000	250x1000	220	20-40	15-50	30	5.6	1400× 1850× 1310
