• Model NO.：PF
• Finished Surface：Hole Process
• Certification：CE, ISO
• Condition：New
• Color：Multi Color
• Delivery Time：Within 15 Days
• Transport Package：Container or in Bulk or Others
• Specification：PF
• Trademark：YUFCHINA
• Origin：China
• HS Code：84741000
• Production Capacity：6000PCS,Year

Basic Info.

Model NO. PF Finished Surface Hole Process Certification CE, ISO Condition New Color Multi Color Delivery Time Within 15 Days Transport Package Container or in Bulk or Others Specification PF Trademark YUFCHINA Origin China HS Code 84741000 Production Capacity 6000PCS/Year

Product Description

We manufacture jaw crusher, impact crusher, hammer crusher, hammer mill, stone crusher, impact fine crusher, cone crusher, roll crusher, double stage crusher, stone crushing machine, stone crushing line, stone crushing and screen line, sand making line, stone production line, river sand making line, gravel making line, Mobile crusher, mobile jaw crusher, mobile impact crusher, mobile stone crusher, mobile crusher station, portable crusher plant, portable crusher station, portable jaw crusher, portable impact crusher, portable cone crusher, portable crusher.

Impact Crusher are optimized after adopting advanced techniques. It widely applied in mining, energy, transportation, construction and chemical industry and mainly used to crush many kinds of large, medium, small hard size materials with compression resistance no more than 350Mpa, in the fields of highway, reservoir, railway, airport and other fields that need rock with cubic shape. It can crush granite, basalt, bluestone, etc the diameters of which are from 100mm to 500mm, and its crushing compression strength is not more than 320MP. They are ideal choice for crushing and screening.

Working Principle Of Impact Crusher:
The materials are crushed via impact energy produced in the impact crusher. When the materials enter the zone of the board hammer, they are flung into the impact equipments via the high-speed impact of the board hammer. These materials will be re-crushed after rebounding into the scale board. The large materials are crushed into small pieces until it becomes the specified granularities. The end products come out from the base of the impact crusher.

Features Of The Impact Crusher:
1. Cubic shaped end products;

2. Adjustable end products sizes, simple crushing process;

3. High chrome and abrasion resistant board hammer, powerful impacting force;

4. Non-key connected, easy maintenance, economical and reliable;

5. Solid construction, high efficiency.

Welcome to Zhengzhou YUFENG Company. If you want to more information about our products, Please give us the message, we will reply as soon as possible.

Type	Spec.	Feeder Opening (mm)	Feeding Size (mm)	Crushing Capacity (t/h)	Motor Power (KW)	Weight (T)
PF-0607	Φ 644× 740	320× 770	100	10-20	30	6
PF-0807	Φ 850× 700	400× 730	300	15-30	30-45	8
PF-1008	Φ 1000× 800	400× 830	300	30-50	37-55	10
PF-1010	Φ 1000× 1050	400× 1080	350	50-80	55-75	12
PF-1210	Φ 1250× 1050	400× 1080	350	70-120	110-132	14
PF-1214	Φ 1250× 1400	400× 1430	350	130-180	132-160	18.6
PF-1315	Φ 1320× 1500	860× 1520	500	160-250	180-260	19
PF-1320	Φ 1320× 2000	860× 2030	500	300-350	300-375	24
