PC Hammer Stone Crusher PC1010

Linyi Raytone Machinery Imp&Exp Co., Ltd.

Type：Hammer Crusher
Application：Machinery & Hardware, Construction, Mineral Industry, Stone Industry
Drive：Electromagnetic
Crushing Style：Grinding & Impact
Compressive Strength (For Crushing)：100-250MPA
Crushing Degree：Coarse Crusher

Base Info

Model NO.：PC1010
Finished Surface：Cut Off Tool
Certification：CE, ISO, SONCAP
Condition：New
Color：Red
Model No.：PC1010
Power：55kw
Feeding Opener：1020*650mm
Capacity：50-90t,H
Output Size：0-100mm
Dimensiojn：1524*1950*1864mm
Crush Type：Hammer
Place of Origin：Shandong Linyi
Delivery Time：20 Days
Engineer Service：Available
Transport Package：Suitable for Sea Transportation
Specification：ISO CE SGS SONCAP
Trademark：Raytone Machinery
Origin：Shandong Linyi
HS Code：8464909000
Production Capacity：50 Sets Per Month

Description

Basic Info.

Model NO. PC1010 Finished Surface Cut Off Tool Certification CE, ISO, SONCAP Condition New Color Red Model No. PC1010 Power 55kw Feeding Opener 1020*650mm Capacity 50-90t/H Output Size 0-100mm Dimensiojn 1524*1950*1864mm Crush Type Hammer Place of Origin Shandong Linyi Delivery Time 20 Days Engineer Service Available Transport Package Suitable for Sea Transportation Specification ISO CE SGS SONCAP Trademark Raytone Machinery Origin Shandong Linyi HS Code 8464909000 Production Capacity 50 Sets Per Month

Product Description

Brief Introduction:

PC hammer crusher has all advantages of impact and hammer Crusher ,it has reasonable structure, stable performance, large crushing ratio, uniform discharge good granularity shape, high-yield and low consumption, easy maintenance, less wearing parts, especially crushing limestone, coarse, medium, crushing only one step, instead of the traditional two crushing process, low investment in infrastructure and equipment, supporting the vibrating feeder without manual operation, higher yields and more economical.

Work Principle

PC series hammer crusher's main parts of efficient compound crusher is rollers with hammer, the rollers consists of main shaft, sphere plate, axis roll and hammer. Motor drives roller in high speed running inner the crushing champ, the materials is send from top into the crusher, by the striking, impacting, shearing and grinding into power. At the roller bottom is a screen plate, it is used to collecting the materials whose size bellow the size of the screen plate, those size is bigger than the screen gap will be regrind by the hammer, finally discharged from the discharging opening.
