• Model NO.：PE500x750, PE600x900, PE750x1060, PE900x1200
• Finished Surface：Hole Process
• Certification：CE, ISO, GOST
• Condition：New
• Color：Iron Grey
• Spare Parts Supply：for Whole Year
• Test&Installation：Engineer Assigned
• After-Sale Service：for Whole Using Life
• Export Markets：Global
• Transport Package：Container, Nude Packs, in Bulk
• Specification：ISO9001: 2000
• Trademark：Zenith
• Origin：Shanghai Zenith, China
• HS Code：8474209000
• Production Capacity：1000 Set,Year

Basic Info.

Model NO. PE500x750, PE600x900, PE750x1060, PE900x1200 Finished Surface Hole Process Certification CE, ISO, GOST Condition New Color Iron Grey Spare Parts Supply for Whole Year Test&Installation Engineer Assigned After-Sale Service for Whole Using Life Export Markets Global Transport Package Container, Nude Packs, in Bulk Specification ISO9001: 2000 Trademark Zenith Origin Shanghai Zenith, China HS Code 8474209000 Production Capacity 1000 Set/Year

Product Description

50-800tph ISO CE Certificate stone crusher machine price

 Features of stone crusher machine price
1. Unit Integration: Superior performance of complete set, reasonable & compact configuration, low requirements to working site.
2. Nice maneuver performance: Compact structure for whole set, short turning radius, easy to go in & out and convert working site.
3. Energy-saving & high efficiency: Mobile crusher is able to get into raw material site direct to work, for which transportation of raw material can be omitted. Therefore, transport cost for raw material is saved.
4. Additive generator unit: mobile can be configured with generator unit in case the normal working under electro less or power outage so as to ensure continuous working and production.
Technical guarantee, smooth and superior performance: nearly 30 year mining equipment technology and experience create the mobile crusher with simple, reasonable and compact structure.


Characteristics of stone crusher machine price

1. Optimization design of ship form frame structure, the low vehicle chassis, compact and reasonable structure, modular assembly structure, small turning radius and convenient transporation.

2. Folding type feeding bin, hydraulic support guard board, easy and reliable operation

T3. he control cabinet equips with the advanced words touch control screen, PLC control system, ensureing the function of starting, process adjustment, misoperation tip and protection, electrical control operation, fault and safety tip.

4. The feeder can presort fines, automatic design for silo door, controlling the direction of dividing material

5. The angle of conveyor is adjustable, and the conveyor can be turned and folded, extending operation conditions, easy for transporation.

6. Adopt stream-line design for vehicle structure, compact and reasonable mechanics optimization structure.

7. Landing leg can hydraulically rise and fall, easy and flexible for operation.


stone crusher machine price parameters:


Model	Specs. of screening equipment	Specs. of crushing equipment	Specs. of main belt conveyor	Hopper volume(m3)	Max.feeding size (mm)	Transportation dimension(mm)
KE600-1	TSW0936	PE600×900	B800×8.3m	5.3	500	12150×2600×3950
KE750-1	TSW1139	PE750×1060	B1000×8.5m	7	630	13000×2850×4400
KE760-1	TSW1139	PEW760	B1000×8.5m	7	640	13000×2800×4200
KE860-1	TSW1345	PEW860	B1200×9.5m	8	720	14600×3000×4500
KE1100-1	TSW1548	PEW1100	B1400×9.5m	11	930	14050×2900×4000
KJ98-1	TSW1139	HJ98	B800×8.3m	5.9	560	12150×2600×3950
KJ110-1	TSW1345	HJ110	B1000×8.5m	8.5	660	13200×3000×4400
KJ125-1	TSW1345	HJ125	B1400×9.5m	8	800	14600×3000×4500
KF1214II-1	TSW0936	PFW1214II	B800×8.3m	5.3	500	12150×2600×3980
KF1315II-1	TSW1345	PFW1315II	B1200×9.5m	8	600	14600×3100×4500
KF1415II-1	TSW1548	PFW1415II	B1200×9.5m	11	700	14050×3000×4000
