• Model NO.：SG-2050AH SG-2050AHR SG-2050AHD
• Grinding Machine Type：Vibration Polishing Machine
• Grinding Method：Semi-Dry Grind
• Certification：ISO, CE
• Condition：New
• Power(W)：1500W
• Table Size(Wxl)：200X400
• Max. Longitudinal Travel：510mm
• Max. Cross Travel：238mm
• Max. Distance From Spindle Center to Tab：450mm
• Transport Package：Ply Wood
• Specification：CE
• Trademark：can use customer brand
• Origin：China
• HS Code：84660900
• Production Capacity：100,Per Month

SG SGA saddle moving surface grinder   Item/Model UnitSG-2050H/AH  SG-2050AHR  SG-2050AHDtable size(WxL)mm200x400max. longitudinal travel mm510max. cross travelmm238max. distance from spindle center to tablemm450electro magnetic chuck sizemm200x460speed of table longitudinal movementm/min7-23table transverse movementauto feedmm/min0.1-8rapid speedmm/min990feed of handwheelmm/div0.02wheelhead vertical movementauto feedmm---(H/AH/AHR model) 0.005/0.01/0.02/0.03/0.04/0.05(only for AHD model)rapid speedmm/min---(H/AH model) / 460 (for AHR model)feed of handwheelmm/div0.005grinding wheelspeedrpm2850(50Hz),3450(60Hz)eize(ODxWxID)mm200x20x31.75spindle motorkw1.5hydranlic motorkw0.75cooling pump motorkw0.04elecating motorkw---(Ah model) 0.25(AHR model) 0.5(AHD model servo motor)cross feed motorkw1.04max.loading capacity of table(include chuck)kg120total rated powerkw3height of machinemm1675floor space(LxW)mm2050x1400Gross weightkg1600package dimensions(LxWxH)mm1900x1720x2175
