• Model NO.：1325
• Current：AC
• Application：Ceramics, Decoration, Advertising, Art & Craft, Stela & Gravestone, Stone Industry
• Customized：Customized
• Guild Rail：Hiwin Square Rail
• Ball Screw：PMI, Taiwan
• Control System：Nc Studio
• Invertor：Fuling
• Working Voltage：380V,220V
• Transport Package：Standard Exported Plywood Case
• Specification：CE
• Trademark：dongtong
• Origin：Shandong China
• HS Code：84609090
• Production Capacity：50 Sets Per Month

Basic Info.

Model NO. 1325 Current AC Application Ceramics, Decoration, Advertising, Art & Craft, Stela & Gravestone, Stone Industry Customized Customized Guild Rail Hiwin Square Rail Ball Screw PMI, Taiwan Control System Nc Studio Invertor Fuling Working Voltage 380V/220V Transport Package Standard Exported Plywood Case Specification CE Trademark dongtong Origin Shandong China HS Code 84609090 Production Capacity 50 Sets Per Month

Product Description

Heavy-duty Stone CNC Router
Marble, Granite, Bluestone, Sandstone, Glass, Wood, Aluminum,
CNC Engraving Machine, from professional stone cnc router manufacturer.


1. Model: DT-1325
2. Internationally advanced NC studio system which have memory of breakpoint can guarantee resumption
Of processing in case of incident (breaking) or of work of the previous day.
3. Imported linear square rails, double big slider, loading capacity,
Smooth operation, high precision, long life, accurate operation.
4. Constant power spindle motor, strong and accurate cutting, high efficiency


Granite, marble, bluestone, sandstone, glass, wood, aluminum.









NO	Performance index	Performance index	Parameter	Optional
1	Working area	X area	1300mm	As your request
		Y area	2500mm
		Z area	300mm
2	Table size		1300mm*2500mm
3	Accuracy	Working precision	0.05mm
		Repositioning precision	0.05mm
4	Drive mode	X axis	Rack gear
		Y axis	Rack gear(dual-moter)
		Z axis	Screw
5	Speed	Max traverse speed	30000mm/min
		Max engraving speed	8000mm/min
6	Spindle (water-cooling)	Spindle power	4.5KW	1.5KW_5.5KW
		Spindle speed	0_24000r/min
7	Working mode		Stepper	Servo
8	Operating voltage		AC220V/50HZ	As your request
9	Command code		G code
10	Operating system		NC Studio
11	Net weight		2520KG



Heavy-duty Stone CNC Router
Marble, Granite, Bluestone, Sandstone, Glass, Wood, Aluminum,

If you have specific requirement for  heavy duty wood/stone cnc router, please contact with us.
Customization is available.
