Large Capacity Commercial Rock Crushers with ISO Approval
Shanghai Zenith Mineral Co., Ltd.- Type：Jaw Crusher
- Application：Construction, Mineral Industry, Stone Industry
- Drive：Hydraulic
- Crushing Style：Extruding & Milling
- Compressive Strength (For Crushing)：>300MPA
- Crushing Degree：Fine Grinding Machine
Base Info
- Model NO.：S series
- Finished Surface：Hole Process
- Certification：CE, ISO, GOST
- Condition：New
- Color：Iron Grey
- Spare Parts Supply：for Whole Year
- Test&Installation：Engineer Assigned
- After-Sale Service：for Whole Using Life
- Export Markets：Global
- Transport Package：Container, Nude Packs, in Bulk
- Specification：ISO9001: 2000
- Trademark：Zenith
- Origin：Shanghai Zenith, China
- HS Code：8474209000
- Production Capacity：40-850tph
Description
ModelMovable Cone Diametermm (inch) Chamber Style Opening Side Closed Side Discharging Opening (mm) REV (r/min) Power (kw) Motor Model Capacity (t/h) Machine Size (mm) Max.Feeding (mm) 36(3′) 900 (3′) medium 83 102 9-22 580 6-75 Y315S-6/75 45-91 2821×1880 ×2164 coarse 159 175 13-38 59-163 36(3′) 914 (3′) fine 13 41 3-13 580 6-75 Y315S-6/75 27-90 2821×1880 ×2410 medium 33 60 3-16 27-100 coarse 51 76 6-19 65-140 51(4.25′) 1295 (4 1/4′) fine 109 137 13-31 485 6-185 Y355M2-6/185 109-181 2800×2342 ×2668 medium 188 210 16-31 132-253 coarse 216 241 19-51 172-349 51(4.25′) 1295 (4 1/4′) fine 29 64 3-16 485 6-160 Y355M1-6/160 36-163 2800×2342 ×2668 medium 54 89 6-16 82-163 coarse 70 105 10-25 109-227 66(5.5′) 1650 (5 1/2′) fine 188 209 16-38 485 6-240 181-327 3911×2870 ×3771 medium 213 241 22-51 258-417 coarse 241 268 25-64 299-635 66(5.5′) 1650 (5 1/2′) fine 35 70 5-13 485 6-240 90-209 3917×2870 ×3771 medium 54 89 6-19 136-281 coarse 98 133 10-25 190-336 84(7′) 2134 (7′) fine 253 278 19-38 435 6-400 381-726 5200×4300 ×4700 medium 303 334 25-51 608-998 coarse 334 369 31-64 870-1400 84(7′) 2134 (7′) fine 51 105 5-16 435 6-400 190-408 5200×4300 ×4700 medium 95 133 10-19 354-508 coarse 127 178 13-25 454-599
